M150 V2 AA/14500 USB Magnetic Rechargeable flashlight

From $54.90 $42.90

Clear
SKU: N/A Category:
Description




M300 flashlightm300 edit level

M150 AA/14500 magnetic charging flashlight

LED: CREE XP-L2

Max output: ANSI 750 Lumens

Max runtime: Few months

Max beam distance: 110 m (14500) / 61 m (Ni-MH)

Max peak beam intensity: 3000 cd (14500) / 930 cd (Ni-MH)

Waterproof: IPX-8

Impact resistant: 1 Meter

Battery: 1×14500 , 1x AA

Rated Range: 0.8V ~ 4.2V

Dimension:

Length 84.0mm / 3.30 inch

Head diameter 21.0mm / 0.82 inch

Body diameter 18.0mm / 0.71 inch

Weight: 34 g / 1.20 oz (without battery)

Accessories: User manual,Spare O-rings,Lanyard,Clip, Magnetic Charging Cable .

Operation

1,Battery installation & Replace magnet:

Insert the battery positive pole toward the light head.,otherwise it will not work. When the light turning on,the beam is directed away from the eyes.When take the light with Bankcards(magnetic) or cellphone, should replaced Magnet with rubber pad.

  1. Turn ON/OFF & Mode transfer

Transfer Mode A / Mode B:

When headlamp is turned off without lockout, hold press side switch 5 seconds, light will flash three times faster then flash three times slow.



Mode Group A

When the flashlight was OFF status:

Click switch to memorized brightness level.

Quickly double click switch to Turbo(T1/T2).

Quickly triple click switch to Strobe(S1) mode.

Press switch 0.5 second to Low(L1/L2) mode.



When the flashlight was ON(any mode) status:

Press and hold the side switch 0.5 second to turn off.



  1. Brightness & mode selection:

Brightness level:

Press side switch to Low-Mid-High-Turbo, cycle.

Quickly double press the side switch to Sub-level(i.e between L1 & L2), turn off memorized the last brightness.

Quickly triple press to Special modes.



Special modes:

Quickly triple press the side switch to Strobe (S1), then double-click to switch S1/S2/S3 mode, Press side switch back to previous brightness level.



Mode Group B

When the flashlight was OFF status:

Click switch to memorized brightness level.

Press switch 0.5 sec,to L2.

Quickly double click switch to Turbo(T1) mode.

Quickly triple press to Special modes(S1).



When the flashlight was ON(any mode) status:

Click switch to turn off.

On Common used levels(Editable):

Hold press switch, brightness levels automatic cycle, and selected mode by button released. Click switch to turn off.

Quickly triple press enter to Edit levels.

On Special modes:



Quickly double click switch to transfer mode S1/S2/S3,click switch to turn off.

Hold press side switch 1 second to adjust the S1/S2/S3 brightness output level in Low, medium or high.

Quickly triple press to restore to the factory default flash modes.



Edit Levels:

— Support to 2 ~ 7 common used levels can be selected

–Enter to edit level, 7  levels circle automatically. The selected level, side switch indicatior is on. Not selected brightness, side switch indicator is off.

–Factory’s default levels: L2-M2-H2-T2. The indicator light on synchronously when levels automatic cycles.

–Selected / Not selected brightness, Click side switch to turn on / off the corresponding indicator.



-. All selected finished, hold press 1 second the side switch save selected and quit edit mode. The light will be flash three times, and back to the lowest selected level.

-. Restore the factory default levels: Enter to edit level, then click side switch three times. (Light will be turn off after three clicks.)



4.Location indicator & Lock-out function

When turn off the flashlight, press switch 1.5 second,location indicator switch on and lock-out function activation at same time,click switch only can switch the indicator on/off, the indicator light flash every second, locate the flashlight, Easy find the flashlight in the dark quickly.Press switch 1.5 sec, switch unlock and enter into low mode.



  1. Power indicator

Every time turn on , the side indicator will be light 5 seconds to display the battery power.

Blink four times : battery power in 100%~80%;

Blink three times : battery power in 80%~50%;

Blink twice : battery power in 50%~20%;

Blink one time : battery power below 20%.

5. Charging instructions and notices:

In charging, the red indicator constant light on, when battery almost full charge,indicator change to constant blue light.

Warning: Rechargeable function only for one 14500 (3.6/3.7V) rechargeable lithium battery! Please make sure the battery is correctly insert, otherwise it will damage the charging system.

Features

1.Super bright & latestCREE XP-L2 LED, Max 750 lumens. High-Performance, High-Efficiency and energy conservation.
2.New U.D.O.C Reflector. Increased reflectivity over 10%., Efficiency reflection, perfect beamshot, excellent structure and temperature resistance.
3.Built-in magnetic charging system, fast charge and convenient.
4.Rugged indestructible aluminum body with anti-scratching type III hard anodization
5.Multi-level dissipating heat designand new copper starboard, excellent heat dissipation. Flashlight head integrated construction, high thermal conductivity.
6.Side switch button to transferring mode user-friendly interface to adjust output.
7.Two mode groups to meet different use habits, suitable for different environment.
8.Wide input range provides more choices of batteries. High efficiency driver circuit, no visible flash in any mode.
9.Automatic memory function, remember last used setting and can be preset to specific output mode for instant access.
10.Intelligent temperature control technology for flashlight stable and safe use.
11.Reverse polarity protection, to protect from improper battery installation.
12.When turn off, hold press button to activate lockout function. Avoid light turn on by unexpected.
13.When light lockout, location indicator will flash, easy get the light in dark.
14.Magnetic tail, can be used in many special occasions, use as candlelight, etc.

Usage and Maintenance

Use quality batteries so as not to damage the light due to leaks or other self-destructive possibilities.

Remove batteries when light will not be used for an extended period or if batteries are discharged.

When using Li-ion batteries,we recommends the use of protected batteries. Clean contacts, threads and O-rings of the flashlight with clean cloth from

time to time when necessary.

Should flickers or doesn’t light up this the most likely cause.

If flashlight is used in wet environment, lubricate O-rings frequently to

maintain watertight seal. inspected and cleaned if necessary.

Products Warranty

1.SKILHUNT warrants our products  to be free from defects in materials

and workmanship.

2.Within 15 days of purchase,any defective lights will be offered free

replacement by SKILHUNT distributors unconditionally.except for damage

caused by misuse or insert batteries in wrong way or batteries weeping.

3.Within 24 months from the day of purchase.

SKILHUNT offers free repair after service,except for damages caused by

misuse or insert batteries in wrong way or batteries weeping.

4.Limited lifetime warranty.

SKILHUNT will still provide with warranty service.

Labor is free but we will charge for parts.

The total repair fee is assessed according to the cost of the replaced materials.

Freight should be paid by customers.

5.More details about warranty service,please contact local distributors or dealers
